D6C60-F1-LFS
Manufacturer:
C&K Components
Mfr.Part #:
D6C60-F1-LFS
Datasheet:
Description:
Pushbutton Switches Through Hole SPST Off-Mom Current Rating:100 mA
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 32 V |
| Termination | PC Pin |
| Diameter | 12 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -20 °C |
| Number of Pins | 4 |
| Power Rating | 3 W |
| Circuit Type | SPST |
| Packaging | Box |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Contact Plating | Silver |
| Number of Terminals | 4 |
| Terminal Pitch | 5 mm |
| Current Rating | 100 mA |
| Max Current Rating | 100 mA |
| Max Voltage Rating (DC) | 32 V |
| Orientation | Straight |
| Color | Blue |
| Actuator Length | 4 mm |
| Throw Configuration | SPST |
| Number of Positions | 2 |
| Row Spacing | 5 mm |
| Switch Function | Off-Mom |
| Electrical Life | 250 kcycles |
| Operating Force | 1.3 N |
| Contact Current Rating | 100 mA |
| Cap Color | Blue |
| Illumination Color | Blue |
| Termination Style | PC Pin |
